Accessory cables

NMEA 2000 cables

Part Number Description

000-0124-69 NMEA 2000 STARTER KIT:

120 OHM RES FEM BLK

120 OHM RES MALE BLK

N2K-T-RD T-CONNECTOR

N2KEXT-2RD 2’ (0.61M) EXTENSION CABLE

N2KEXT-15RD 15’ (4.55M) EXTENSION CABLE

N2K-PWR-RD POWER CABLE

000-10996-001 N2K 4-WAY BLOCK MICRO -C

000-0127-52 TERMINATING RESISTOR KIT (MALE AND FEMALE)

000-0119-79 N2K-T-RD T-CONNECTOR

000-0119-75 N2K-PWR-RD POWER CABLE

000-0119-88 N2KEXT-2RD 2’ (0.61M) EXTENSION CABLE

000-0127-53 N2KEXT-6RD 6’ (1.82M) EXTENSION CABLE

000-0119-86 N2KEXT-15RD 15’ (4.55M) EXTENSION CABLE

000-0119-83 N2KEXT-25RD 25’ (7.58M) EXTENSION CABLE

000-0127-45 SIMNET - NMEA 2000 ADAPTER KIT:

SIMNET CABLE JOINER

CABLE MICRO-C MALE to SIMNET 0.5M

N2K-T-RD T-CONNECTOR

24005729 SimNet to Micro–C male plug, 0.5m (cable for connection of a SimNet

device to a NMEA 2000 backbone)

24006199 SimNet to Micro-C female plug, 1m (cable for connection of a NMEA

2000

device to SimNet backbone)

24006413 SimNet to Micro-C female, 4m (13 ft) (cable for connection of a NMEA

2000 device to SimNet backbone)

Ethernet cables

Part Number Description

000-0127-28 Ethernet cable yellow 5 Pin 0.6 m (2 ft)

000-0127-51 Ethernet cable yellow 5 Pin 2 m (6.5 ft)

000-0127-29 Ethernet cable yellow 5 Pin 4.5 m (15 ft)

000-0127-30 Ethernet cable yellow 5 Pin 7.7 m (25 ft)

000-0127-37 Ethernet cable yellow 5 Pin 15.2 m (50 ft)
