Specications | NSS Installation Manual
Multi Function Display NSS7 NSS8 NSS12 Display Display resolution 480 x 640 (H x W) 800 x 600 (H x W) 1024 x 768 (H x W) Display type 6.4 inch VGA color TFT LCD 8 inch SVGA color TFT LCD 12.1 inch XGA TFT LCD Display brightness 1200 nits 1200 nits 1200 nits Touch screen Yes Power Power supply 12 - 24 V DC (9-32.0 V DC min - max) 12 - 24 V DC (9-32.0 V DC min - max) 12 - 24 V DC (9-32.0 V DC min - max) Power consumption 10.4 W (0.8 A @ 13 V DC) 15.6 W (1.2 A @ 13 V DC) 26 W (2.0 A @ 13 V DC) Technical / Environmental Housing Plastic housing; Die cast rear heatsink Temperature -15° C to + 55° C (+5° F to +131° F) Waterproof standard IPx7 Certicate of conformity CE(EN60945: 2002) / C-tick / CSS Interface Ethernet 1 Port 1 Port 3 Ports NMEA 2000 Micro-C (1) Video input Composite video (2) (multiplexed) Data card slot Micro SD (1) Other Weight (display only) 1.6 kg (3.5 lb) 2.1 kg (4.6 lb) 3.78 kg (8.3 lb) Pack dimensions (L x W x H) 30.5 x 27.9 x 27.9 cm (12" x 11" x 11") 40.6 x 27.9 x 25.4 cm (16" x 11" x 10") Pack weight 2.54 kg (5.6 lb) 2.9 kg (6.5 lb) Echo sounder Sonar frequency 50/200 or 83/200 kHz 50/200 or 83/200 kHz Not applicable Sonar output power Max 250 W peak to peak (31 W RMS)
actual
Max 250 W peak to peak (31 W RMS) actual
Not applicable
Specications
21

Simrad NSS7 Specifications

General

Screen Resolution	800 x 480 pixels
Chartplotter	Yes
Ethernet Ports	1
NMEA 2000	Yes
Screen Size	7 inches
Operating Frequency	50/200 kHz
