Wiring the NSS
Wiring guidelines
Don’t do this Do this
Don’t make sharp bends in the cables Do make drip and service loops
Don’t run cables in a way that allows water to
ow down into the connectors
Do tie-wrap all cables to keep them secure
Don’t route the data cables in areas adjacent
to radar, transmitter, or large current carrying
cables
If cables are shortened, lengthened, or re-
terminated, do insulate and protect all wiring
connections
Do leave room at the back to install and
remove cables
Warning: Before starting the installation, be sure to turn electrical power o. If power is
left on or turned on during the installation, re, electrical shock, or other serious injury may
occur. Be sure that the voltage of the power supply is compatible with the NSS display
Warning: The NSS has a voltage rating of 12 V DC or 24 V DC. (9 V DC - 32 V DC max
range). SimNet is 12 V DC only
