Ethernet (NETWORK port) | NSS Installation Manual
Expanding the NSS12
With the NSS12, up to three ethernet devices can be connected directly to the unit. If more
than three modules need connection, use the optional network expansion port (NEP-2).
Broadband RadarBSM-1
NSS12
A second NSS connected to one of the NSS12’s three built in ports will have full visibilty and
control over any devices connected to another port on the NSS12, in the same way it would if
all devices were connected via an NEP-2 expansion port.
Transducer
Broadband Radar
NSS12
NSS7
