Configure NMEA 0183 ports
Baud rate
This should be set to correspond with devices connected to the
NMEA 0183 input and output. The input and output (Tx, Rx) use the
same baud rate setting.
Ú
Note: AIS transponders typically operate at NMEA 0183-HS
(high speed), and will require the baud rate to be set to 38,400.
NMEA 2000 installer notes
Used to identify a device in the NMEA 2000 device list.
Serial input sentences
This list allows control over which sentences that are received from
other devices from the NMEA 0183 port.
Serial output sentences
This list allows control over which sentences that are transmitted to
other devices from the NMEA 0183 port. Due to the limited
bandwidth of NMEA 0183 it is desirable to only enable the data that
is required. The less sentences that are selected, the higher the
output rate of the enabled sentences.
Software setup | P2005/P3007 Operator Manual
37
