SIUI CTS-900 - Page 123

Acoustic Output Parameter
D-3
Transducer Model：C5I20H Operating Mode：M
TIS TIB
Non-scan
Index Label
MI
Scan
A
aprt≤1cm² Aaprt＞1cm²
Non-
scan
TIC
Global Maximum index value 0.682 0.065 0.128 0.078
Prα Mpa 1.489
P mW 4.0 4.0
Min.of[Pα(zs),Ita,α(zs)] mW
zs cm
zbp cm
zb cm 150
z at max. Ipi,α cm 1.65
deq(zb) cm 0.433
fawf MHz 4.712 4.712 4.442 4.712
X cm 1.20 1.20
Associated
Acoustic
parameters
Dim of
A
aprt
Y cm 1.07 1.07
td μsec 0.404
p rr Hz 512
pr at max. Ipi Mpa 1.90
deq at max. Ipi cm 0.408
Other
information
I
pi,α at max.MI W/cm² 82.83
Control 1:
Power
dB 0 0 0 0
Control 2:
Focal Depth
cm 4.0 4.0 4.0 4.0
Control 3:
M Speed
s 1.25 1.25 1.25 1.25
Operating
Control
conditions
Control 4:
Frequency
MHz 5.0 5.0 5.0 5.0
