on “+/-” to set the standard voltage to 6.0V;
3. Tap on “SET”, in the screen it pops up “Calibrating Succeed”, the calibration is
finished.
Steps to Calibrate the Telemetry Voltage of the Aircraft Power (POW)
1. Power on the sky station through the POW port, the voltage range is from 3.3V
to 50V, measuring with a multi-meter;
2. Let’s take an example of 25V; select “Standard Voltage” in the POW menu, tap
on “+/-” to set standard voltage to 25V;
3. Tap on “SET”, in the screen it pops up “Calibrating Succeed”, the calibration is
finished.
7.3 PWM Settings
In the DK32S transmitter and the PWM mode, users can redefine the output
channel of the sky station (channel 1-9 in default), so that if the channel 9 is
already working in SBUS or PPM mode, the PWM ports 1 to 8 can still output to the
channels 1 to 16 of the transmitter.
