Section 10 TECHNICAL DATA
Subsection 03 (VEHICLES)
10-03-2
VEHICLE MODEL FORMULA 500
FORMULA 500
DE LUXE
FORMULA 583
DE LUXE
FORMULA Z 583
ENGINE TYPE 494 494 583 583
Chain Drive Ratio 23/43 23/44 25/44 25/43
Chain
Pitch in 3/8 3/8 3/8 3/8
Type/Links Qty/Plates Qty Silent 72/11 Silent 72/11 Silent 74/13 Silent 74/13
Drive Pulley
Type of Drive Pulley TRA TRA TRA TRA
Ramp Identification 286 ➄ 286 ➄ 286 ➄ 286 ➄
Calibration Screw Position or
— calibration disc quantity
3333
Spring Color Violet/Blue Violet/Blue Violet/Blue Violet/Blue
Spring Length
± 1.5 mm
(± .060 in)
114.6
(4.51)
114.6
(4.51)
114.6
(4.51)
114.6
(4.51)
Clutch Engagement ± 200 RPM 3800 3800 4100 4100
Driven Pulley Spring Preload
Cam Angle
± 0.7 kg (±1.5 lb)
Degree
7.0 (15.4)
50°
7.0 (15.4)
50°
7.0 (15.4)
50°
7.0 (15.4)
50°
Pulley Distance Z
(+ 0, –1) mm
((+ 0, –1/32) in)
16.5
(21/32)
16.5
(21/32)
16.5
(21/32)
16.5
(21/32)
Offset
X ± 0.4 mm (± 1/64 in) 35.0 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8)
Y – X MIN. – MAX.
mm
(in)
1.0 – 2.0
(.039 – .079)
1.0 – 2.0
(.039 – .079)
1.0 – 2.0
(.039 – .079)
1.0 – 2.0
(.039 – .079)
Drive Belt Part Number (P/N) 414 8607 00 414 8607 00 414 8607 00 414 8607 00
Drive Belt Width (new) ➀ mm (in) 35.3 (1-3/8) 35.3 (1-3/8) 35.3 (1-3/8) 35.3 (1-3/8)
Drive Belt Adjustment
Deflection
± 5 mm
(± 13/64 in)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
Force ➁ kg (lbf) 11.3 (25) 11.3 (25) 11.3 (25) 11.3 (25)
Track
Width cm (in) 38.1 (15.0) 38.1 (15.0) 38.1 (15.0) 38.1 (15.0)
Length cm (in) 307 (121) 307 (121) 307 (121) 307 (121)
Profile Height mm (in) 18.4 (.724) 18.4 (.724) 23.2 (.913) 23.2 (.913)
Adjustment
Deflection
mm
(in)
35 – 40
(1-3/8 – 1-3/4)
35 – 40
(1-3/8 – 1-3/4)
35 – 40
(1-3/8 – 1-3/4)
35 – 40
(1-3/8 – 1-3/4)
Force ➂ kg (lbf) 7.3 (16) 7.3 (16) 7.3 (16) 7.3 (16)
Suspension Type
Track SC-10 Sport SC-10 Sport SC-10 Sport SC-10 HP
Ski DSA DSA DSA DSA
Length cm (in) 272.5 (107.3) 272.5 (107.3) 272.5 (107.3) 272.5 (107.3)
Width cm (in) 120.7 (47.5) 120.7 (47.5) 120.7 (47.5) 120.7 (47.5)
Height cm (in) 108 (42.5) 108 (42.5) 108 (42.5) 108 (42.5)
Ski Stance cm (in) 106.7 (42) 106.7 (42) 106.7 (42) 106.7 (42)
Mass (dry) kg (lb) 212 (467) 228 (502) 239 (526) 227 (499)
Ground Contact Area
cm
2
(in
2
)
6485 (1005) 6863 (1064) 6863 (1064) 6793 (1053)
Ground Contact Pressure kPa (PSI) 3.21 (.465) 3.26 (.473) 3.42 (.496) 3.24 (.470)
Frame Material Aluminum Aluminum Aluminum Aluminum
Bottom Pan Material Impact Copolymer Impact Copolymer Impact Copolymer Impact Copolymer
Hood Material RRIM Polyurethane RRIM Polyurethane RRIM Polyurethane RRIM Polyurethane
Battery V (A•h) N.A. 12 (22) 12 (22) N.A.
Headlight W H4 60/55 H4 60/55 H4 60/55 H4 60/55
Taillight and Stoplight W 8/27 8/27 8/27 8/27
Tachometer and Speedometer Bulbs W 2 x 3 2 x 3 2 x 3 2 x 3
Fuel and Temperature Gauge Bulbs W N.A. N.A. N.A. 3/3
Fuse
Starter Solenoid A N.A. 30 N.A. N.A.
Tachometer A N.A. N.A. N.A. N.A.
Fuel Tank L (U.S. gal) 40 (10.6) 40 (10.6) 40 (10.6) 40 (10.6)
Chaincase/Gearbox mL (U.S. oz) 250 (8.5) 250 (8.5) 250 (8.5) 250 (8.5)
Cooling System ➃ L (U.S. oz) 4.7 (159) 4.7 (159) 4.7 (159) 4.7 (159)
Injection Oil Reservoir L (U.S. oz) 2.8 (95) 2.8 (95) 2.8 (95) 2.8 (95)
