Section 03 TROUBLESHOOTING
Subsection 05 (ELECTRICAL SYSTEM)
03-05-9
SYMPTOM REAR LIGHT BULB FLASHES.
CONDITION NORMAL USE.
Test/Inspection 1. Check bulb tightness in housing.
a. Looseness at bulb contact elements.
Install bulb correctly.
2. Check if rear light is properly connected.
a. Connector housing is partially connected.
Install connector housing properly.
3. Check continuity of wires.
a. Corroded terminals and/or broken wires.
Replace terminal(s) or crimp defective wires.
SYMPTOM TACHOMETER DOES NOT WORK.
CONDITION NORMAL USE.
Test/Inspection 1. Check continuity of wires.
a. Corroded terminals and/or broken wires.
Replace terminal(s) or crimp defective wires.
SYMPTOM HIGH BEAM PILOT LAMP LIGHTS UP WHEN LOW BEAM IS SELECTED.
CONDITION NORMAL USE.
Test/Inspection 1. Check proper connections.
a. YELLOW wire connected to pilot lamp. Mixed-up connections with heating
element pilot lamps.
Reconnect a YELLOW/BLACK wire to pilot lamp. YELLOW wires are connected to
heating element pilot lamps.
