Section 04 ENGINE
Subsection 02 (443 AND 503 ENGINE TYPES)
04-02-4
ENGINE REMOVAL AND
INSTALLATION
Disconnect or remove the following:
– negative cable from battery
– positive cable and wire from starter then from
engine
– belt guard
– drive belt
– drive pulley using appropriate puller, refer to 05-03
DRIVE PULLEY
– air silencer and carburetor
– impulse line from engine crankcase
– 4-connector housing
– exhaust pipe and exhaust cooling hose
– oil pump inlet tube and plug it
– oil pump cable
– rewind cable: tie a knot near rewind housing
and remove starting grip
â—†
WARNING
Before disconnecting any electrical wire in
starter system always first disconnect the
BLACK negative battery cable (on electric
starting models).
