WARNING
If lock nuts are not tightened prop-
erly, the adjusting screws could
loosen causing the track to be-
come extremely loose and, under
some operating conditions, allow
the idler wheels to climb over the
track lugs forcing the track against
the tunnel causing the track to
“lock”. Properly tighten wheel re-
taining screws, otherwise wheel
maycomeoffandcausetrackto
“lock”.
1
2
A05F0EB
TYPICAL
1. Retighten (so equipped models)
2. Retighten to 48 N•m (35 lbf•ft)
Restart engine and rotate track slowly
to recheck alignment.
Reposition snowmobile on ground.
106
