EXPEDITION TUV
MODEL
600 HO SDI
REAR SUSPENSION
Suspension type RCG1-W
Suspension maximum travel mm (in) 295 (11.61)
Center
Gas
Shock absorber type
Rear
HPG
Stroke limiter standard position
4-2
STEERING SYSTEM
Ski type ADJ
Toe-out mm (in) 5 (.197)
Camber
0°
VEHICLE INFORMATIONS
Mass (dry) kg (lb) 326 (718.7)
Length m (in) 3.13 (123.2)
Width m (in) 1.17 (46)
Height m (in) 1.35 (53)
Ski stance (carbide to carbide) mm (in) 985 (38.8)
(1)
Measure gap between slider shoe and bottom inside of track when exerting a downward pull to the track.
(2)
Equal distance between edges of track guides and slider shoes.
(3)
Drive belt height must be adjusted every time a new drive belt is installed. Confirm drive belt part number
application with an authorized SKI-DOO dealer.
80
