EXPEDITION TUV
MODEL
600 HO SDI
DRIVE SYSTEM
Type XP-S synthetic chaincase oil
Gearbox oil
Quantity ml (U.S. oz) 500 (16.9)
1
st
1 : 2.82
2
nd
1 : 1.70Gear ratio
R
1 : 3.44
Drive pulley type TRA III
Drive pulley calibration Clutch engagement 3000 ± 100 RPM
Driven pulley type 6-K VSA
Drive belt P/N
605 348 425
(3)
Width mm (in) 37.3 (1.469)
Drive belt
Wear limit mm (in) 35.8 (1.409)
Deflection mm(in) 32±5(1.260±.197)
Drive belt adjustment
Force kgf (lbf) 11.30 (24.91)
Width mm (in) 500 (20)
Length m (in) 3.968 (156)Track
Profile height mm (in) 31.8 (1.25)
Deflection
(1)
mm (in) 40 to 50 (1.575 to 1.969)
Force
(1)
kgf (lbf) 7.3 (16)Track adjustment
Alignment
(2)
BRAKE SYSTEM
Brake lining thickness Service limit mm (in) 1 (.039)
Type DOT 4
Brake fluid
Quantity ml (U.S. oz) 500 (17)
FRONT SUSPENSION
Suspension type SUV
Suspension maximum travel mm (in) 200 (7.9)
Shock absorber type Gas
_____________________
79
