EXPEDITION TUV/SKANDIC SWT
MODEL
V800
FUEL SYSTEM
Gas type Unleaded
Inside North America ((R+M)/2) 87 or higher
Pump octane number
Outside North America (RON) 92 or higher
Fuel tank capacity L (U.S. gal) 41 (10.8)
ELECTRICAL SYSTEM
Magneto generator output W 460 @ 6000 RPM
Ignition type
CDI (Capacity Discharge Ignition)
by DENSO
Make and type NGK DCPR8E
Spark plug
Gap mm (in) 0.75 (.0303)
Battery 12 V, 21 A•h
Headlamp W 60/55 (H4)
Taillight and stoplight W 8/27
Fuse Refer to FUSES section
DRIVE SYSTEM
Type XP-S synthetic chaincase oil
Gearbox oil
Quantity ml (U.S. oz) 500 (16.9)
1
st
1 : 3.80
2
nd
1 : 2.29
SWT
R1:4.63
1
st
1 : 2.82
2
nd
1 : 2.04
Gear ratio
TUV
R
1 : 3.44
Drive pulley type TRA IV
Drive pulley calibration Clutch engagement 2500 ± 100 RPM
Driven pulley type 6-K VSA
Drive belt P/N
605 348 425
(3)
Width mm (in) 37.3 (1.469)
Drive belt
Wear limit mm (in) 35.8 (1.409)
82
