EXPEDITION TUV/SKANDIC SWT
MODEL
V800
DRIVE SYSTEM (cont'd)
Deflection mm(in) 32±5(1.260±.197)
Drive belt adjustment
Force kgf (lbf) 11.30 (24.91)
SWT mm (in) 600 (24)
Width
TUV mm (in) 500 (20)
Length m (in) 3.968 (156)
Track
Profile height mm (in) 31.8 (1.25)
Deflection
(1)
mm (in) 40 to 50 (1.575 to 1.969)
Track adjustment
Force
(1)
kgf (lbf) 7.3 (16)
BRAKE SYSTEM
Brake lining thickness Service limit mm (in) 1 (.039)
Type DOT 4
Brake fluid
Quantity ml (U.S. oz) 500 (17)
FRONT SUSPENSION
SWT LTS
Suspension type
TUV SUV
SWT mm (in) 150 (6)
Suspension maximum travel
TUV mm (in) 200 (8)
Shock absorber type Motion control
REAR SUSPENSION
SWT Easy ride XWLS
Suspension type
TUV RCG1-W
SWT mm (in) 210 (8.3)
Suspension maximum travel
TUV mm (in) 293 (11.5)
Center Motion control
Shock absorber type
Rear HPG
_____________________
83
