19
SKOPE Reflex Upright Fridge, Freezer, Combo
Wiring
Service Manual
CAUTION
Some connector colours vary depending on date of manufacture.
Refer to Plug type/colour column in the table below for colour variations.
After unplugging connectors, ALWAYS ensure reconnection has been undertaken
correctly as operational faults may occur if incorrect. It is recommended to
photograph wiring setup before unplugging for future reference.
LEGEND
Internal Unit Junction Box Sockets/Plugs
Name Description
Plug type/colour
Before Feb. 2020 From Feb. 2020
Inlet IEC Cabinet Socket/Plug IEC IEC
S1/P1 Not Used - -
S2/P2 Unit Junction Box to Controller Signal Socket/Plug White 6-way White 6-way
S3/P3 Unit to Controller Power Socket/Plug Blue 4-way Black 4-way
S4/P4 Heater Wire Unit Socket/Plug Black 3-way Black 3-way
S5/P5 Light Unit Socket/Plug White 3-way White 3-way
S6/P6 Unit to Controller Power Socket/Plug 1 Red 4-way Orange 4-way
S7/P7 Door Sensor Socket/Plug White 2-way White 2-way
S8/P8 Compressor Unit Socket/Plug Blue 4-way Blue 4-way
S9/P9 Evaporator Sensor Socket/Plug Black 2-way Black 2-way
S10/P10 Cabinet Sensor Socket/Plug Blue 2-way Blue 2-way
S11/P11 Defrost Element Socket/Plug Yellow 4-way Yellow 4-way
S12/P12 Condenser Motor Unit Socket/Plug Red 4-way Red 4-way
S13/P13 Evaporator Motor Unit Socket/Plug White 4-way White 4-way
S14/P14 Condenser Sensor Socket/Plug Red 2-way Orange 2-way
S15/P15 Ambient Sensor Socket/Plug White 2-way White 2-way
S16/P16 Programming/Comms Port Socket Blue 4-way Blue 4-way
S17/P17 LED Driver DC Out Put Socket/Plug Red 2-way Red 2-way
S18/P18 LED Lighting Loom Socket/Plug Yellow 4-way Green 4-way
T1 Unit Terminals - -
