Skope ReFlex Upright - Door Hinges; Door Locks

35
SKOPE Reflex Upright Fridge, Freezer, Combo
Replacement Procedures
Service Manual
Door Hinges Each door is fitted with top and bottom hinges, and an additional self-closing
mechanism which allows the door to self-close. The hinges and self-closing
mechanism are replaceable.
To remove the hinges
Door Locks The sign is fitted with a key lock for each door. The lock bolt and lock barrel
can be removed and replaced.
1. Remove the top hinge,
washers and bush from the
top of the door.
2. Unscrew and remove the
bottom hinge and washers
from the bottom of the door.
3. Unscrew and remove the
self closing hinge from the
bottom of the door.
