Replacement Procedures
Service Manual
SKOPE Reflex Upright Fridge, Freezer, Combo
Castors and Legs
The cabinet is supplied fitted with swivel castors. The front castors are
braked, the rear castors are swivel only. A set of adjustable height legs is
also included in the cabinet.
The castors can be removed for plinth mounting or for fitting the height
adjustable legs.
To remove the castors
To fit the height adjustable legs
To plinth mount
1. Raise the cabinet off the
ground, and unbolt the
castors from the bottom of
the cabinet.
1. The supplied legs fit onto the castor mounting holes.
1. The underside of the cabinet is completely flat for plinth mounting.
