34
Replacement Procedures
Service Manual
SKOPE Reflex Upright Fridge, Freezer, Combo
Doors
Alignment
Adjustment
If a door is out of alignment, realign it by loosening the top and or bottom
hinge bracket fixing screws, move the door as required, and re-tighten the
hinge bracket screws.
Door Gasket The one-piece door gasket clips into the door frame and runs around the
perimeter of the door. Remove the gasket by peeling it from the door frame,
starting at a corner.
If the gasket is out of shape after refitting, use a hair dryer to heat and
reshape it.
Removing and
Refitting the
Door
For ease of servicing, and to reverse the hinging (1-Door models only, see
page 36), the door can be removed from the cabinet.
To remove the door
To refit the door
Door Tension The door is fitted with a self-closing mechanism which allows the door to
self-close. If door tension is lost, check that the self-closing mechanism is
installed correctly, and if still no tension replace the self-closing mechanism
(see “Door Hinges” on page 35).
1. Disconnect the cabinet from the power supply.
2.
Open the door/s, unscrew the front panel - (Phillips head screwdriver): Two
screws on the bottom edge of the panel.
Swing the front panel up and tape/
restrain safely in place (see picture on page 42).
3. Unscrew the top and bottom hinges and remove door from cabinet.
4. If necessary, remove top and bottom hinges, and self-closing mechanism (see
“Door Hinges” on page 35). Ensure all bushes and washers are present, and
the self-closing mechanism is fitted in closed position for correct self closing.
1. If necessary, refit self-closing mechanism and top and bottom hinges. Ensure
all bushes and washers are present, and the self-closing mechanism is fitted in
closed position for correct self closing.
2. Refit the door to the cabinet.
3. Check that the door switch magnet aligns with the door switch at the top of the
door opening. If the magnet does not align: reposition, drill holes and refit in the
correct alignment.
4. Check that the door seal gasket is fitted correctly and forms a complete seal
with the cabinet when the door is closed(e.g lantern inside cabinet to check for
gaps)
