Skytrak MMV - Rail Transportability and GIC Clearance

General Maintenance
229
Model MMV Rev. 10/11
Rail Transportability and GIC Clearance
Refer to the following diagram.
MIRROR TO BE
ROTATED INWARD
50" (1270 mm)
NORTH AMERICAN
RAIL TRANSPORT
GAUGE
NATO GIC
EQUIPMENT GAUGE
APPROX. 45°
TIRE PROTECTIVE
MATERIAL
OM1261
