24
Model MMV Rev. 10/11
Operation
Ignition Switch
The ignition switch (1) is located on the right side of the lower front dash.
The switch may be turned clockwise from the OFF (2) position to the RUN
(3) and START (4) positions. To rotate the switch to the START position,
push the switch IN and rotate to the START position. The START position is
spring-loaded to return to the RUN position and must be manually held in
place for starting.
OFF position (2) — The entire electrical system is shut down.
RUN position (3) — All controls and indicators are operable.
START position (4) — Engages starter motor to crank the engine when the
parking brake switch is engaged and the transmission is in NEUTRAL.
