Operation
29
Model MMV Rev. 10/11
Travel Select Lever
The Travel Select Lever (3) has three positions to select direction of travel:
F = FORWARD (4) ......... all the way UP
N = NEUTRAL (5) .......... CENTER position
R = REVERSE (6)...........all the way DOWN
To change travel selections, move the lever UP or DOWN to the desired
selection.
When the Travel Select Lever is shifted to REVERSE, the back-up alarm
will automatically sound. When the blackout light system is activated the
back-up alarm will not operate.
NOTE: The Travel Select Lever must be in the (N) NEUTRAL position to
permit engine starting.
