Skytrak MMV - Mode 2 A - Tilt and Boom Control

Operation
31
Model MMV Rev. 10/11
Attachment Tilt Mode Switch
The Attachment Tilt Mode Switch (2) has
two positions which allow the operator to
chose between the Lift/Lower function
and the Extend/Retract function
accompanying the Attachment Tilt capability. For detailed information, see
“Multi-Function Joystick Operation” starting on page 32.
OS2120
2
OM1830
