76
Model MMV Rev. 10/11
Operation
Starting Travel
1. Enter the operator cab, fasten the seat belt, start the engine, apply
the service brake pedal and disengage the parking brake switch.
2. Rotate the twist grip of the range select lever to 1st gear.
3. Move the travel select lever (5) to (F) FORWARD (6) to travel in a
forward direction or to (R) REVERSE (7) to travel backward.
4. Slowly remove your foot from the service brake pedal and press the
accelerator pedal to start travel.
IMPORTANT! Check for warning lights frequently during operation. Any
abnormal indication should be corrected as soon as practical.
Changing Travel Direction
1. Stop the vehicle by applying the service brakes.
2. Grasp the travel select lever (5), pull it toward the steering wheel,
then move the lever up or down in the opposite direction;
(R) REVERSE (7) or (F) FORWARD (6).
