Operation
75
Model MMV Rev. 10/11
Slow Pivot Mode
With the boom above 40° (1), the Stabil-TRAK System is now in the SLOW
PIVOT MODE (2). In this mode the rear axle is UNLOCKED and is allowed
to pivot but will respond SLOWLY
to changes in terrain. The Stabil-TRAK
slow pivot light on the front dash panel will be ON (3). The Stabil-TRAK lock
light on the front dash panel will be OFF (4).
The frame sway control will function normally in this mode.
To check that the Stabil-TRAK System is functioning properly, refer to the
test procedure on page 237 for the proper system function.
0000000
RPM X 100
5
10
15
30
20
25
F
1/2
E
104
176
80
248
120
°C
°F
D
r/min
