40
Model MMV Rev. 10/11
Operation
Operators Seat Adjustments
The operator’s seat can be adjusted three ways:
Fore and Aft Adjustment
Pull the handle (1) outward to adjust the seat forward and
backward. Release the handle to lock the seat in the desired
position.
Suspension Adjustment
Turn the knob (2) on the front of the seat to adjust the suspension to
correspond with the operator’s weight. Turn clockwise to increase
stiffness. Turn counter-clockwise to reduce the stiffness.
Backrest Angle Adjustment
The angle of the seat backrest can be adjusted to suit the operator.
Move the lever (3) located on the left side the seat backrest to
adjust the angle.
