Skytrak MMV - Boom Lift;Lower & Frame Sway Right;Left

Operation
37
Model MMV Rev. 10/11
Boom Lift/Lower & Frame Sway Right/Left
(Depress left & front buttons simultaneously, then hold either button)
This mode is accomplished by using the multi-function joystick (4) and
depressing the front (5) and left (6) buttons simultaneously, then while
holding either button, move the joystick to the required function. As the
mode is activated the corresponding lights will illuminate on the logic panel
(7).
Boom Lift............................... move handle backward
Boom Lower.......................... move handle forward
Frame Sway Right .................move handle to the right
Frame Sway Left....................move handle to the left
Mode 3
OS0611
4
OM0710
7
5
6
4
6
