Test Procedures
239
Model MMV Rev. 10/11
Step 7:
a. With the parking brake switch
ON, move the travel select lever
to the (N) NEUTRAL position.
b. Lower the boom to exactly 45°
.
c. Frame sway the vehicle no more than 5°
to the left.
d. Frame sway the vehicle back to 0°.
e. Frame sway the vehicle no more than 5°
to the right.
NOTE: Observe that frame sway will be slower than normal during this test.
f. The Stabil-TRAK Lock light should remain ON and the front left
tire should remain off the ground. The front left tire should not
raise or lower during frame sway.
g. Frame sway back toward 0°, leaving the vehicle swayed to the
right approximately 1° to 2°.
Step 8:
a. Depress the service brake pedal.
b. Disengage the parking brake switch.
c. With the range select lever in (1) FIRST gear, move the travel
select lever to the (R) REVERSE position.
d. Release the service brake pedal to deactivate the Stabil-TRAK
system.
e. The Stabil-TRAK Lock light should go OFF and the Stabil-
TRAK Slow Pivot light should come ON.
f. The front left tire should return to the ground while the vehicle
travels in reverse.
g. Depress the service brake pedal to stop the vehicle.
