Operation
87
Model MMV Rev. 10/11
8. Remove the protective caps from the quick couplers. Connect the
quick couplers in the following order: Connect the YELLOW (1)
then the GREEN (2) on the right side. Connect the BLACK (3) then
the RED (4) on the left side.
9. In the event there is trapped pressure in one of the carriage hydrau-
lic hoses, connect the quick coupler(s) with a firm constant motion.
This will allow the (specially designed) male quick coupler to drain
the trapped pressure through to the female coupler and into the
hydraulic system.
10. Return to the cab, fasten the seat belt and resume operation.
WARNING: DO NOT operate this vehicle unless you
are in the seat with the seat belt fastened around you. Death or
serious personal injury could result if the belt is not securely fas-
tened.
