5. Use the right fork shift switch (1) to move the right fork on the 7K
carriage to the left, enough for the back of the right fork to rest
tightly against the weldment on the back of the 11K carriage. Use
the left fork shift switch (2) to move the left fork on the 7K carriage
to the right, enough for the back of the left fork to rest tightly against
the other weldment.
6. Place the travel selector in NEUTRAL (N) and engage the parking
brake.
7. Exit the operators compartment and visually confirm that both 7K
forks are fully engaged behind the weldments on the back of the
11K carriage.
8. Raise the boom and the 7K carriage into the travel position. The
11K carriage can now be transported.
