SMA Solar Technology AG Commissioning
Installation Guide SWebBox20-IEN110711 21
6.2 Configuring Bluetooth Settings for the Sunny WebBox
The Bluetooth settings of the Sunny WebBox are to be made via the rotary switch of the Bluetooth
module using a screwdriver (2.5 mm).
1. Turn the "MODE" rotary switch to position "0". The rotary switch must always be set to position
"0" (status on delivery). Other positions are not permitted and are intended for SMA Service
only.
2. Turn the arrow of the "NetID" rotary switch to the
NetID of the PV plant. For a layout of the switch
positions, see table.
☑ The Sunny WebBox is prepared for Bluetooth communication.
Now you can connect the Sunny WebBox to the computer with which you would like to configure the
Sunny WebBox (see page 22).
NOTICE
Changing the NetID during operation of the Sunny WebBox
If the NetID of the Sunny WebBox is changed, the Sunny WebBox is restarted. Then all
devices with the same NetID are searched for and displayed in the plant tree.
NetID 1 is currently not supported by the Sunny WebBox with Bluetooth.
A direct connection to an individual SMA Bluetooth device via NetID 1 is currently only
possible with the Sunny Explorer software or the Sunny Beam with Bluetooth.
Change the NetID of the Sunny WebBox with Bluetooth to the NetID of your PV plant
(NetID 2 to NetID F).
NetID Function
0 Bluetooth is switched off.
1 (Status upon delivery) No function
2-F Bluetooth is switched on.
The Sunny WebBox can network with all SMA Bluetooth
products with the same NetID. A connection to the Sunny
Beam with Bluetooth or Sunny Explorer is not possible.
