Maintenance and Care SMA Solar Technology AG
44 SWebBox20-IEN110711 Installation Guide
8.5 Determining Current Settings of the Sunny WebBox via the SD
Card
The following steps allow you to determine the current settings and the current firmware of the Sunny
WebBox if you do not have access to the user interface.
Take note of the information on the SD card (see section 13.1 "Information on the SD Card"
(page 55)).
1. Insert the SD card into the Sunny WebBox SD card slot.
☑ The Sunny WebBox creates a folder with the name "WEBBOX_[Serial number]" on the SD
card and saves the "config.xml" file there. The writing process is complete when the "SD
CARD" LED is permanently lit. Example: WEBBOX_0155000123\config.xml
2. When the "SD CARD" LED is permanently lit, remove the SD card from the Sunny WebBox SD
card slot.
3. Read off the SD card using a computer with an SD card reader.
4. Open the "config.xml" file in the WebBox_[serial number] folder with a text editor or a web
browser.
☑ Read the values of the network settings of the Sunny WebBox (see section 13.2 "Structure of
the Config.xml File" (page 55)).
9 Maintenance and Care
9.1 Maintenance
Conduct regular visual inspections of the Sunny WebBox to check for external damages or soiling.
9.2 Care
NOTICE
Damage to the device due to ingress of liquids.
• The Sunny WebBox is not waterproof. Protect the Sunny WebBox from wet
conditions.
• When cleaning the device, only use a lightly damp cloth in order to prevent water
from entering the device. If there is a considerable amount of dirt, you can also use
a mild, non-abrasive, non-corrosive cleaning agent.
