SMART Board SB480iv2 - Integrating Your System with Peripheral Devices

CHAPTER 2
INSTALLING YOUR INTERACTIVE WHITEBOARD SYSTEM
13 smarttech.com/kb/170782
No. Connector Connect to:
9
DB15F RGB VGA video input (VGA
In)
Computer standard definition multimedia (audio
and video) source (not included)
10
RCA analog composite video
(yellow)
Composite video input that supports legacy
NTSC, PAL and SECAM video standards (e.g. VCR
or DVD players) (not included)
11
3.5 mm phone jack audio input
(composite video)
Audio sources associated with the computer
connected to the composite video input source.
12 3.5 mm phone jack audio input
(shared by VGA 1 and VGA 2 input)
Audio sources associated with the computer
connected to the VGA video input source.
NOTES
l To connect your SMARTBoard M680V interactive whiteboard or SMARTBoard 480
interactive whiteboard, see the SMARTBoard 480iv2 and M680Viv2 interactive
whiteboard system textless installation guide (smarttech.com/kb/170779).
l To connect accessories to your interactive whiteboard, refer to the documents included
with the accessories and consult the SMARTSupport website (smarttech.com/support) for
additional information.
Integrating your system with peripheral devices
For information on integrating your SMARTBoard 480iv2 or M680Viv2 interactive whiteboard
system with peripheral devices, see Connecting peripheral sources and outputs on page64.
