SMART Board SB480iv2 - Integrating Other Devices

Appendix D
61 smarttech.com/kb/170782
Appendix D: Integrating other devices
Video format 61
Native video format 61
Video format compatibility 62
HD and SD signal format compatibility 63
Video system signal compatibility 64
Connecting peripheral sources and outputs 64
This appendix provides information on integrating your SMARTBoard interactive whiteboard
system with peripheral devices.
Video format
Your projector has a native video format and various video format compatibility modes. You can
change image appearances for certain formats and compatibilities.
Native video format
The following table lists the native VESA RGB video format and digital HDMIvideo format for the
projector.
Resolution Mode Aspect ratio Refresh rate
(Hz)
Horizontal
frequency
(kHz)
Pixel clock
(MHz)
1280 × 800 WXGA 16:10 60 48 83.5
