Resolution Mode Aspect ratio Refresh rate (Hz) “Match Input”
appearance
1280 × 1024 SXGA3 85 5:4 85.024
Pillarbox
1400 × 1050 SXGA+ 4:3 59.978
Pillarbox
1600 × 1200 UXGA 4:3 60
Pillarbox
1680 × 1050 WSXGA+ 16:10 60 Native
1920 × 1080 HD 1080 16:9 60 Letterbox
HD and SD signal format compatibility
The following tables list the projector’s high definition and standard definition format signal
compatibility, which you can adjust by using the aspect ratio commands described in Adjusting
projector settings on page55.
Signal format Aspect ratio Horizontal
frequency (kHz)
Vertical
frequency (Hz)
“Match Input”
appearance
480i (525i) 4:3 15.73 59.94 Full screen
480p (525p) 4:3 31.47 59.94 Full screen
576i (625i) 5:4 15.63 50 Pillarbox
576p (625p) 5:4 31.25 50 Pillarbox
720p (750p) 16:9 45 59.94 Letterbox
720p (750p) 16:9 37.5 50 Letterbox
1080i (1125i) 16:9 33.75 59.94 Letterbox
1080i (1125i) 16:9 28.13 50 Letterbox
1080p (1125p) 16:9 67.5 59.94 Letterbox
1080p (1125p) 16:9 56.25 50 Letterbox
NOTE
Your projector is HD-ready. Its native resolution supports a pixel-perfect display of 720p source
content. However, because the projector compresses 1080p source content to fit its native
resolution, it doesn’t support a pixel-perfect display of 1080p source content.
