CHAPTER 3
USING YOUR INTERACTIVE WHITEBOARD SYSTEM
18 smarttech.com/kb/170782
Adjusting projector settings
The remote control’s Menu button enables you to access the on-screen display to adjust the
projector settings.
IMPORTANT
Keep your remote control in a safe place because there is no other way to access menu options.
Setting Use Notes
Picture menu
Color Mode Indicates the projector’s
display output (Bright
Classroom, Dark Classroom,
SMARTPresentation, Game
and User).
The default is SMARTPresentation.
Brightness Sets projector brightness from
0 to 100.
The default is 47.
Contrast Sets the difference between
the lightest and darkest parts
of the image from 0 to 100.
The default is 55.
Sharpness Sets the projected image’s
sharpness from 0 to 31.
The default is 15.
Saturation Sets the projected image’s
color saturation from 0 to 100.
The default is 50.
Hue Sets the image hue from 0 to
100.
The default is 50.
Gamma Sets the gamma from 0 to 3. The default is 0.
Color Temp Sets the color temperature
(Low, Mid and High).
The default is Low.
Color Space Configures the signal color
space (Auto, RGB and YUV).
The default is Auto.
Position menu
Aspect Ratio Sets the image output to Auto,
4:3, 16:9 and 16:10.
The default is Auto.
Phase Set lock phase which affects
the horizontal position of the
image.
Automatically determined by VGAsource
input.
