SMART Board MX Series Installation And Maintenance Guide

Chapter 2 Installing the display
smarttech.com/kb/171555 21
Important
l
Move the display at your own risk. SMART cannot accept liability for damages or injury that occur
during the display’s transportation.
l
When moving the display:
o
Follow local safety regulations and standards.
o
Pack the display in its original packaging, including the pallet.
o
Move the display so that its top frame faces up.
o
Have at least two people move the display.
Tip
Display packaging may be labeled to indicate which side is the front. Look for “FRONT” on the
packaging to help orient the box during transportation.
Using transportation aides
You can use the following aides to move the display:
l
Cart
l
Furniture dolly
l
Mechanical lift
Accommodating doorways, hallways, and elevators
In some situations, you might need to remove the display from its packaging to move it through narrow
doorways or hallways or onto an elevator. In these situations, keep the foam pieces on the bottom
corners of the display. These foam pieces protect the display if you need to set it down during
transportation.
You might also need to rotate the display so that its top frame faces to the side. You can do this during
transportation, but when you install the display, it must be in landscape orientation (with the top frame
facing up).

SMART Board MX Series Specifications

General

Screen Sizes	65", 75", 86"
Touch Points	20
Aspect Ratio	16:9
Response Time	8 ms
Viewing Angle	178°
Integrated Speakers	Yes
Internal Storage	16 GB
VESA Mount Compatibility	Yes
Warranty	3 years
Display Type	LCD
Brightness	350 cd/m²
Inputs	HDMI, USB, VGA
Operating System Compatibility	Windows, macOS, Chrome OS
Operating System	Android
Processor	Quad-Core
Dimensions	Varies by size
Touch Technology	Infrared
Weight	Varies by size: 65" - 45.6 kg, 75" - 62 kg, 86" - 78 kg
