Chapter 3 Connecting computers and other devices
smarttech.com/kb/171555 52
No. Connector Connects to Notes
1 HDMI 1.4 out (HDCP-
compliant)
External monitor This connector is HDCP-encrypted
HDMI.
Note
HDMIout is an optional feature.
Contact your authorized SMART
reseller (smarttech.com/where)
for further ordering instructions.
2 USB 2.0 Type-A
connector
Supported USB drives,
peripherals, and other
devices
Connect a USBdrive to update the
display’s firmware.
Note
If troubleshooting an issue with
the display, connect a USB
mouse to navigate the display’s
on-screen menu.
3 USB 2.0 Type-A
connector
Supported USB drives,
peripherals, and other
devices
See page43 and USB cables and
connectors.
4 HDMI 1 2.0 in HDMI 1 input
(videoandaudio)
See page36 and HDMI cables
and connectors.
5 HDMI 2 2.0 in HDMI 2 input
(videoandaudio)
See page36 and HDMI cables
and connectors.
6 RJ45 (×2) Network See page29 and Ethernet
(network) cables and connectors.
7 USB 2.0 Type-B HDMI 1, HDMI 2, or VGA input
(touch)
See page36 and USB cables and
connectors.
8 RS-232 Room control system See page94 and RS-232 cables
and connectors.
9 Stereo 3.5 mm out External audio system See page45 and Analog audio
cables and connectors.
10 S/PDIF out Digital audio output See page45 and Digital audio
cables and connectors.
11 Stereo 3.5 mm in VGA input (audio) See page36 and Analog audio
cables and connectors.
12 VGA in VGA input (video) See page36 and VGA cables and
connectors.
