SMART Board MX Series Installation And Maintenance Guide

Chapter 4 Maintaining the display
smarttech.com/kb/171555 62
If the display is connected to a computer and the pointer appears a distance from the actual contact
when you touch the screen, orient the display.
Note
You can use your finger or a pen to orient the display.
To orient the display when connected to a computer
1. Open SMARTSettings.
Operating
system
Procedure
Windows
®
10
a.
Select Start.
b.
Scroll to and select SMART Technologies > SMARTSettings.
Windows 8
a.
Open the Apps screen.
b.
Scroll to and select SMART Technologies > SMARTSettings.
Windows 7
Select Start > All Programs > SMART Technologies >
SMARTTools>SMARTSettings.
macOS
a.
Press on the Mac menu bar.
b.
Press SMARTSettings.
2.
Tap Orient.
3. Tap the red targets as they appear. Hold your finger or the tip of the pen at the center of each
target, and then lift the pen or finger. When you lift the pen or finger, the target moves to the next
orientation point.
Important
Hold the pen at a right angle to the screen.
4. Continue until you’ve pressed all the targets.
The orientation window closes.

SMART Board MX Series Specifications

General

Screen Sizes	65", 75", 86"
Touch Points	20
Aspect Ratio	16:9
Response Time	8 ms
Viewing Angle	178°
Integrated Speakers	Yes
Internal Storage	16 GB
VESA Mount Compatibility	Yes
Warranty	3 years
Display Type	LCD
Brightness	350 cd/m²
Inputs	HDMI, USB, VGA
Operating System Compatibility	Windows, macOS, Chrome OS
Operating System	Android
Processor	Quad-Core
Dimensions	Varies by size
Touch Technology	Infrared
Weight	Varies by size: 65" - 45.6 kg, 75" - 62 kg, 86" - 78 kg
