Smartgen HGM9510 User Manual

HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 22 of 65
No
Type
Description
18
Oil Pressure Open
Circuit
When the controller detects that the oil pressure sensor is open
circuit and the action select “Shutdown”, it will initiate a shutdown
alarm.
19
Low Oil Pressure
When the controller detects that the oil pressure has fallen below
the pre-set value, it will initiate a shutdown alarm.
20
Level Sensor Open
Circuit
When the controller detects that the level sensor is open circuit
and the action select “Shutdown”, it will initiate a shutdown alarm.
21
Flexible Sensor 1
Open Circuit
When the controller detects that the flexible sensor 1 is open
circuit and the action select “Shutdown”, it will initiate a shutdown
alarm.
22
Flexible Sensor 1
High
When the controller detects that the sensor 1 value has exceeded
the pre-set value, it will initiate a shutdown alarm.
23
Flexible Sensor 1
Low
When the controller detects that the sensor 1 value has fallen
below the pre-set value, it will initiate a shutdown alarm.
24
Flexible Sensor 2
Open Circuit
When the controller detects that the flexible sensor 2 is open
circuit and the action select “Shutdown”, it will initiate a shutdown
alarm.
25
Flexible Sensor 2
High
When the controller detects that the sensor 2 value has exceeded
the pre-set value, it will initiate a shutdown alarm.
26
Flexible Sensor 2
Low
When the controller detects that the sensor 2 value has fallen
below the pre-set value, it will initiate a shutdown alarm.
27
Digital Input
When digit input port is set as shutdown and the alarm is active, it
will initiate a shutdown alarm.
28
Earth Fault
If earth fault detection is enabled, when the controller detects that
the earth fault current has exceeded the pre-set value and the
action select “Shutdown”, it will initiate a shutdown alarm.
29
Negative Sequence
Current
When the controller detects the imbalance current has exceeded
the pre-set value and the action select “Shutdown” it will initiate a
shutdown alarm.
30
MSC Too Few Sets
When the controller detects fewer modules on the MSC link than
the minimum number configured in the unit, it will initiate a
shutdown alarm. There are 2 possible reasons: a) Communication
line between the controllers disconnects, which interrupts
communication.
b) Other parallel gen-sets controllers have not been powered on.
31
MSC ID Error
When the controller detects the same ID on the MSC Bus, it will
initiate a shutdown alarm.
32
Gen Phase
Sequence Wrong
When the controller detects a phase rotation error, it will initiate a
shutdown alarm.
33
Bus Phase Sequence
Wrong
When the controller detects a bus phase rotation error, it will
initiate a shutdown alarm.
34
Bus Error
When the controller detects the voltage difference between
generator and bus, it will initiate a shutdown alarm.
35
Loss of Excitation
When the controller detects that the genset negative reactive
power has exceeded the pre-set value, it will initiate a shutdown
alarm.
