HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 43 of 65
Close when probably condition output S3 is active /inactive: close when active (disconnect when
inactive);
When input port 1 active or input port 2 active, if input port 3 is active, Defined combination output
is outputting; If input port 3 inactive, Defined combination output is not outputting;
When input port 1 inactive and input port 2 inactive, whatever input port 3 is active or not, Defined
combination output is not outputting.
8.3 DEFINED CONTENTS OF PROGRAMMABLE INPUT PORTS (ALL
ACTIVE WHEN CONNECT TO GRAND (B~))
Form 3
No.
Type
Description
0
Users Configured
Including following functions,
Indication: indicate only, not warning or shutdown.
Warning: warn only, not shutdown.
Shutdown: alarm and shutdown immediately
Trip and stop: alarm, generator unloads and shutdown
after hi-speed cooling
Trip: alarm, generator unloads but not shutdown.
Never: input inactive.
Always: input is active all the time.
From crank: detecting as soon as start.
From safety on: detecting after safety on run delay.
1
Reserved
2
Alarm Mute
Can prohibit “Audible Alarm” output when input is active.
3
Reset Alarm
Can reset shutdown alarm and trip alarm when input is
active.
4
60HZ Active
Use for CANBUS engine and it is 60Hz when input is
active.
5
Lamp Test
All LED indicators are illuminating when input is active.
6
Panel Lock
All buttons in panel is inactive except
and there is in the left of first row in LCD when input is
active.
7
Reserved
8
Idle Control Mode
Under voltage/frequency/speed protection is inactive.
9
Inhibit Auto Stop
In Auto mode, during generator normal running, when
input is active, prohibit generator shutdown
automatically.
10
Inhibit Auto Start
In Auto mode, prohibit generator start automatically
when input is active.
11
Inhibit Scheduled
In Auto mode, prohibit fixed timing start genset when
input is active.
12
Reserved
13
Aux Gen Closed
Connect generator loading switch’s Aux. Point.
