HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 5 of 65
1 OVERVIEW
HGM9510 controller is designed for manual/auto parallel system generators with similar or
different capacity. Additionally, it is suitable for single unit constant power output and mains
paralleling. It allows automatic start/stop, parallel running, data measurement, alarm protection as
well as remote control, remote measurement and remote communication function. It fit with LCD
display, optional Chinese, English and other languages interface, and it is reliable and easy to
use.
Utilizing the GOV (Engine Speed Governor) and AVR (Automatic Voltage Regulator) control
function, the controller is able to synchronize and share load automatically; it can be used to
parallel with other HGM9510 controller.
HGM9510 controller also monitors the engine, indicating the operational status and fault
conditions accurately. When abnormal condition occurs, it splits bus and shuts down the genset,
simultaneously the exact failure mode information is indicated by the LCD display on the front
panel. SAE J1939 interface enables the controller to communicate with various ECU (ENGINE
CONTROL UNIT) which fitted with J1939 interface.
The powerful 32-bit Microprocessor contained within the module allows for precision parameters
measuring, fixed value adjustment, time setting and set value adjusting and etc..Majority
parameters can be configured from front panel, and all parameters can be configured by USB
interface (or RS485) to adjust via PC. It can be widely used in all types of automatic gen-set
control system with compact structure, advanced circuits, simple connections and high reliability.
