Smartgen HGM9510 User Manual

HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 41 of 65
122
Generator Reverse
Power
Action when controller detects generator have reverse
power.
123
Over Current
Action when over current.
124
NEL1 Trip
Details of function description please see the following.
125
NEL2 Trip
126
NEL3 Trip
127~138
Reserved
139
High Temp Warn
Action when hi-temperature warning.
140
Low Temp Warn
Action when low temperature warning.
141
High Temp Shutdown
Action when hi-temperature Shutdown alarm.
142
Reserved
143
Low OP Warn
Action when low oil pressure warning.
144
Low OP Shutdown
Action when low oil pressure shutdown.
145
Oil Pressure Open
Circuit
Action when oil pressure sensor is open circuit.
146
Reserved
147
Low Fuel Level
Action when controller has low oil level alarm.
148
Reserved
149
Reserved
150
Flexible Sensor 1 High
Warn
151
Flexible Sensor 1 Low
Warn
152
Flexible Sensor 1 High
Shut
153
Flexible Sensor 1 Low
Shut
154
Flexible Sensor 2 High
Warn
155
Flexible Sensor 2 Low
Warn
156
Flexible Sensor 2 High
Shut
157
Flexible Sensor 2 Low
Shut
158~229
Reserved
230
Stop Mode
Action in stop mode.
231
Manual Mode
Action in Manual mode.
232
Reserved
233
Auto Mode
Action in Auto mode.
234
Generator Load
235~239
Reserved
8.2.1 DEFINED PERIOD OUTPUT
Defined Period output is composed by 2 parts, period output S1 and condition output S2.
