Smartgen HGM9510 User Manual

HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 63 of 65
16.18 VOLVO-EMS2
Volvo Engine types are TAD734, TAD940, TAD941, TAD1640, TAD1641, and TAD1642.
Terminals of controller
Engine’s CAN port
Remark
programmable output 1
6
ECU stop
Configurable output 1 “ECU stop”
Programmable output 2
5
ECU power
Configurable output 2 “ECU power”
3
Negative power
4
Positive power
CAN GND
-
CAN communication shielding
line(connect with controller’s terminal
only)
CAN(H)
1(Hi)
Using impedance 120Ω connecting line
CAN(L)
2(Lo)
Using impedance 120Ω connecting line
Engine type: Volvo-EMS2
NOTE: When this engine type is selected, preheating time should be set to at least 3 seconds.
16.19 YUCHAI
It is suitable for BOSCH common rail pump engine.
Terminals of controller
Engine 42 pins port
Remark
Fuel relay output
1.40
Connect to engine ignition lock
Start relay output
-
Connect to starter coil directly
CAN GND
-
CAN communication shielding
line(connect with controller’s this terminal
only)
CAN(H)
1.35
Using impedance 120Ω connecting line
CAN(L)
1.34
Using impedance 120Ω connecting line
Battery
Engine 2 pins
Remark
Battery negative
1
Wire diameter 2.5mm
2
Battery positive
2
Wire diameter 2.5mm
2
Engine type: BOSCH
16.20 WEICHAI
It is suitable for Weichai BOSCH common rail pump engine.
Terminals of controller
Engine port
Remark
Fuel relay output
1.40
Connect to engine ignition lock
Start relay output
1.61
CAN GND
-
CAN communication shielding
line(connect to the controller at this end
only)
CAN(H)
1.35
Using impedance 120Ω connecting line
CAN(L)
1.34
Using impedance 120Ω connecting line
Engine type: GTSC1
NOTE: If there is any question of connection between controller and ECU communication,
please feel free to contact Smartgen’s service.
