HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 58 of 65
16.3 CUMMINS QSM11(IMPORT)
It is suitable for CM570 engine control module. Engine type is QSM11 G1, QSM11 G2.
Terminals of controller
C1 connector
Remark
Fuel relay output
5&8
Outside expand relay, when fuel output,
making port 5 and port 8 of C1 be
connected
Start relay output
-
Connect to starter coil directly
Terminals of controller
3 pins data link connector
Remark
CAN GND
C
CAN communication shielding
line(connect with ECU terminal only)
CAN(H)
A
Using impedance 120Ω connecting line
CAN(L)
B
Using impedance 120Ω connecting line
Engine type: Cummins ISB
16.4 CUMMINS QSX15-CM570
It is suitable for CM570 engine control module. Engine type is QSX15.
Terminals of controller
50 pins connector
Remark
Fuel relay output
38
Oil spout switch
Start relay output
-
Connect to starter coil directly
Terminals of controller
9 pins connector
Remark
CAN GND
SAE J1939 shield-E
CAN communication shielding
line(connect with ECU terminal only)
CAN(H)
SAE J1939 signal-C
Using impedance 120Ω connecting line
CAN(L)
SAE J1939 return-D
Using impedance 120Ω connecting line
Engine type: Cummins QSX15-CM570
16.5 CUMMINS GCS-MODBUS
It is suitable for GCS engine control module. Use RS485-MODBUS to read information of engine.
Engine types are QSX15, QST30, QSK23/45/60/78 and so on.
Terminals of controller
D-SUB connector 06
Remark
Fuel relay output
5&8
Outside expand relay, when fuel output,
making port 05 and 08 of the connector
06 be connected.
Start relay output
-
Connect to starter coil directly
Terminals of controller
D-SUB connector 06
Remark
RS485 GND
20
CAN communication shielding
line(connect with ECU terminal only)
RS485+
21
Using impedance 120Ω connecting line
RS485-
18
Using impedance 120Ω connecting line
Engine type: Cummins QSK-MODBUS, Cummins QST-MODBUS, Cummins QSX-MODBUS
