Page #62 background imageLoading...
Page #62 background image
HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 62 of 65
16.15 SCANIA
It is suitable for S6 engine control module. Engine type is DC9, DC12, and DC16.
Terminals of controller
B1 connector
Remark
Fuel relay output
3
Start relay output
-
Connect to starter coil directly
CAN GND
-
CAN communication shielding
line(connect with controller’s terminal
only)
CAN(H)
9
Using impedance 120Ω connecting line
CAN(L)
10
Using impedance 120Ω connecting line
Engine type: Scania
16.16 VOLVO EDC3
Suitable engine control mode is TAD1240, TAD1241, and TAD1242.
Terminals of controller
“Stand alone” connector
Remark
Fuel relay output
H
Start relay output
E
programmable output 1
P
ECU power
Configurable output 1,"ECU power"
Terminals of controller
“Data bus” connector
Remark
CAN GND
-
CAN communication shielding
line(connect with controller’s terminal
only)
CAN(H)
1
Using impedance 120Ω connecting line
CAN(L)
2
Using impedance 120Ω connecting line
Engine type: Volvo
NOTE: When this engine type is selected, preheating time should be set to at least 3 seconds.
16.17 VOLVO EDC4
Suitable engine types are TD520, TAD520 (optional), TD720, TAD720 (optional), TAD721,
TAD722, and TAD732.
Terminals of controller
Connector
Remark
Fuel relay output
Expanded 30A relay, and
relay offers battery
voltage for terminal14.
Fuse is 16A
Start relay output
-
Connect to starter coil directly
1
Connected to negative of battery
CAN GND
-
CAN communication shielding
line(connect with controller’s terminal
only)
CAN(H)
12
Using impedance 120Ω connecting line
CAN(L)
13
Using impedance 120Ω connecting line
Engine type: VolvoEDC4
