Smartgen HGM9510 User Manual

HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 61 of 65
16.12 MTU ADEC(SMART MODULE)
It is suitable for MTU engine with ADEC (ECU8) and SMART module.
Terminals of controller
ADEC (X1port)
Remark
Fuel relay output
X1 10
X1 Terminal 9 Connected to negative of
battery
Start relay output
X1 34
X1 Terminal 33 Connected to negative of
battery
Terminals of controller
SMART (X4 port)
Remark
CAN GND
X4 3
CAN communication shielding
line(connect to controller’s this terminal
only)
CAN(H)
X4 1
Using impedance 120Ω connecting line
CAN(L)
X4 2
Using impedance 120Ω connecting line
Engine type: MTU-ADEC
16.13 MTU ADEC(SAM MODULE)
It is suitable for MTU engine with ADEC (ECU7) and SAM module.
Terminals of controller
ADEC (X1port)
Remark
Fuel relay output
X1 43
X1 Terminal 28 Connected to negative of
battery
Start relay output
X1 37
X1 Terminal 22 Connected to negative of
battery
Terminals of controller
SAM (X23 port)
Remark
CAN GND
X23 3
CAN communication shielding
line(connect with controller’s this terminal
only)
CAN(H)
X23 2
Using impedance 120Ω connecting line
CAN(L)
X23 1
Using impedance 120Ω connecting line
Engine type: Common J1939
16.14 PERKINS
It is suitable for ADEM3/ ADEM4 engine control module. Engine type is 2306, 2506, 1106, and
2806.
Terminals of controller
Connector
Remark
Fuel relay output
1,10,15,33,34
Start relay output
-
Connect to starter coil directly
CAN GND
-
CAN communication shielding
line(connect with controller’s terminal
only)
CAN(H)
31
Using impedance 120Ω connecting line
CAN(L)
32
Using impedance 120Ω connecting line
Engine type: Perkins
