HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 60 of 65
16.9 DEUTZ EMR2
Terminals of controller
F connector
Remark
Fuel relay output
Expand 30A relay,
battery voltage of 14 is
supplied by relay. Fuse is
16A
Start relay output
-
Connect to starter coil directly
-
1
Connect to battery negative pole
CAN GND
-
CAN communication shielding
line(connect with controller’s terminal
only)
CAN(H)
12
Impedance 120Ω connecting line is
recommended.
CAN(L)
13
Impedance 120Ω connecting line is
recommended.
Engine type: VolvoEDC4
16.10 JOHN DEERE
Terminals of controller
21 pins connector
Remark
Fuel relay output
G,J
Start relay output
D
CAN GND
-
CAN communication shielding
line(connect with controller’s terminal
only)
CAN(H)
V
Using impedance 120Ω connecting line
CAN(L)
U
Using impedance 120Ω connecting line
Engine type: John Deere
16.11 MTU MDEC
Suitable for MTU engines, 2000 series, 4000series
Terminals of controller
X1 connector
Remark
Fuel relay output
BE1
Start relay output
BE9
CAN GND
E
CAN communication shielding
line(connect with one terminal only)
CAN(H)
G
Using impedance 120Ω connecting line
CAN(L)
F
Using impedance 120Ω connecting line
Engine type: MTU-MDEC-303
