Smartgen HGM9510 User Manual

HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 9 of 65
4 SPECIFICATION
Parameter
Details
Working Voltage
DC8. 0V to 35. 0V, uninterruptible power supply
Overall Consumption
<4W (Standby mode: ≤2W)
AC Input:
3 Phase 4 Wire
3 Phase 3 Wire
Single Phase 2 Wire
2 Phase 3 Wire
AC 15V - 360V (ph-N)
AC 30V - 620V (ph- ph)
AC 15V - 360V (ph-N)
AC 15V - 360V (ph-N)
Alternator Frequency
50Hz/60Hz
Speed Sensor Voltage
1. 0 V to 24 V (RMS)
Speed Sensor Frequency
Maximum 10,000 Hz
Start Relay Output
16A DC28V power supply output
Fuel Relay Output
16A DC28V power supply output
Flexible Relay Output 1
7A DC28V power supply output
Flexible Relay Output 2
7A DC28V power supply output
Flexible Relay Output 3
7A DC28V power supply output
Flexible Relay Output 4
7A 250VAC passive output
Flexible Relay Output 5
7A 250VAC passive output
Flexible Relay Output 6
7A 250VAC passive output
Case Dimensions
266mm x 182mm x 45mm
Panel Cutout
214mm x 160mm
CT Secondary Current
Rated 5A
Working Conditions
Temperature: (-25~+70)°C Humidity: (20~93)%RH
Storage Conditions
Temperature:(-30~+80)°C
Protection Level
IP55 Gasket
Insulation Intensity
Apply AC2.2kV voltage between high voltage terminal and low
voltage terminal;
The leakage current is not more than 3mA within 1min.
Weight
0.95kg
