HGM9510 GENSET PARALLEL UNIT
HGM9510 Genset Parallel Unit ISSUE 2013-08-06 Version 1.1 Page 57 of 65
16 CONNECTIONS OF CONTROLLER WITH J1939 ENGINE
16.1 CUMMINS ISB/ISBE
Terminals of controller
Connector B
Remark
Fuel relay output
39
Start relay output
-
Connect with starter coil directly
Auxiliary output port 1
Expand 30A relay, battery
voltage of 01,07,12,13 is
supplied by relay
ECU power
Set configurable output 1 as “ECU
power”
Terminals of controller
9 pins connector
Remark
CAN GND
SAE J1939 shield
CAN communication shielding
line(connect with ECU terminal only)
CAN(H)
SAE J1939 signal
Impedance 120Ω connecting line is
recommended.
CAN(L)
SAE J1939 return
Impedance 120Ω connecting line is
recommended.
Engine type: Cummins ISB
16.2 CUMMINS QSL9
Suitable for CM850 engine control module
Terminals of controller
50 pins connector
Remark
Fuel relay output
39
Start relay output
-
Connect to starter coil directly
Terminals of controller
9 pins connector
Remark
CAN GND
SAE J1939 shield-E
CAN communication shielding
line(connect with ECU terminal only)
CAN(H)
SAE J1939 signal-C
Using impedance 120Ω connecting line
CAN(L)
SAE J1939 return-D
Using impedance 120Ω connecting line
Engine type: Cummins-CM850
